Description
The ebm-papst 4114NH6 is a robust Axial Fan engineered for demanding thermal management applications requiring high static pressure and airflow throughput. Utilizing advanced DC motor technology housed within a rugged die-cast aluminum frame, this unit ensures structural rigidity and superior heat dissipation. The aerodynamic impeller design minimizes turbulence while maximizing air delivery, effectively lowering thermal impedance in high-density electronic enclosures. Equipped with precision ball bearings, the 4114NH6 delivers reliable long-term operation under continuous load, making it an optimal solution for critical industrial cooling systems.
Model Number: 4114NH6
Brand: ebm-papst
Product Type: Axial Fan
Rated Voltage: 24VDC
Voltage Range: 16 – 30 VDC
Rated Current: 2.7A
Power Consumption: 65W
Rated Speed: 8400 RPM
Bearing Type: Ball Bearing
Max. Air Flow: 294.3 CFM (500 m³/h / 8.33 m³/min)
Max. Static Pressure: 50.8 mmH₂O (498 Pa / 2.0 inH₂O)
Dimensions: 120x120x38mm
Weight: 0.425 kg
Life Expectancy: 70000 hrs at 40°C
Noise Level: 76 dB(A)
Housing Material: Die-Cast Aluminum
Impeller Material: PA Plastic (UL94V-0)
Termination: 2-Wire Lead
Operating Temperature: -20°C to +65°C
Storage Temperature: -40°C to +80°C
Ingress Protection: IP20
Insulation Class: Class B
Safety Approvals: CE, CSA, UL, VDE
Designed for high-load environments, the 4114NH6 is extensively utilized in telecommunications transmitters and broadcasting equipment where heat dissipation is critical. Its compact yet powerful profile fits seamlessly into server racks and network enclosures, ensuring component stability. Additionally, the 4114NH6 serves effectively in industrial automation control panels and medical imaging devices, providing consistent airflow to prevent thermal throttling in sensitive electronics.
