Description
The Sanyo Denki 9CRV0412P5J201 is a high-static pressure Counter Rotating Fan designed for environments requiring exceptional aerodynamic efficiency within a compact footprint. Engineered with the San Ace 40 9CRV architecture, this unit utilizes dual-motor technology to maximize airflow density and overcome significant system impedance. The robust frame construction ensures structural rigidity under high-velocity operation, while the precision-balanced impeller assembly minimizes vibration. Optimized for thermal management in dense electronics, it delivers a substantial reduction in thermal impedance, ensuring reliable operation for critical components.
Model Number: 9CRV0412P5J201
Brand: Sanyo Denki
Series: San Ace 40 9CRV
Product Type: DC Counter Rotating Fan
Rated Voltage: 12 VDC
Voltage Range: 10.8 – 13.2 VDC
Rated Current: 1.8 A
Power Input: 21.6 W
Rated Speed: 22500 RPM
Max. Air Flow: 31.8 CFM (54.0 m³/h / 0.90 m³/min)
Max. Static Pressure: 107.1 mmH₂O (1050 Pa / 4.22 inH₂O)
Noise Level: 68 dBA
Dimensions: 40 x 40 x 56 mm
Weight: 100 g
Operating Temperature: -20 to +70 °C
Bearing Type: Ball Bearing
Frame Material: Plastic (UL94V-0)
Impeller Material: Plastic (UL94V-0)
Speed Control: PWM Control
Sensor Output: Pulse Sensor
Motor Protection: Locked Rotor Protection, Reverse Polarity Protection
The 9CRV0412P5J201 is specifically engineered for high-density applications where back pressure is a significant challenge, such as 1U server racks and telecommunications switching equipment. Its counter-rotating design allows it to force air through tightly packed components like heatsinks and power supply units with high resistance. Additionally, the 9CRV0412P5J201 is suitable for industrial automation systems and compact medical instrumentation requiring reliable, high-velocity cooling solutions.
