Description
The Sanyo Denki 9EC2048P0J04 is a Centrifugal Fan engineered for mission-critical industrial applications requiring high-pressure airflow delivery against significant system impedance. Utilizing advanced DC motor technology and a precision-balanced impeller, this unit optimizes aerodynamic efficiency while minimizing vibration through enhanced structural rigidity. The robust bearing architecture ensures operational stability under heavy thermal loads, significantly reducing thermal impedance in high-density electronic enclosures. Designed for continuous duty, the fan integrates sophisticated commutation electronics to maintain torque consistency and reliability.
Model Number: 9EC2048P0J04
Brand: Sanyo Denki
Product Type: Centrifugal Fan
Rated Voltage: 48VDC
Voltage Range: 40.8 – 55.2 VDC
Rated Current: 4.4 A
Power: 211.2 W
Rated Speed: 4100 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 618.0 CFM (1050 m³/h / 17.5 m³/min)
Max. Static Pressure: 82.0 mmH₂O (804 Pa / 3.23 inH₂O)
Dimensions: Ø200mm x 70mm
Weight: 1600 g
Life Expectancy: 40000 hrs at 60°C
Speed Control: PWM Control
Sensor: Pulse Sensor
Noise Level: 72 dB(A)
Ingress Protection: IP54 (Optional)
Insulation Class: Class F
Housing Material: Aluminum Die-cast
Blade Material: Plastic (UL94V-0)
Termination: Lead Wires
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +70°C
Mounting Orientation: Any
Protection: Locked Rotor Protection, Reverse Polarity Protection
The 9EC2048P0J04 is specifically deployed in high-impedance ventilation systems such as telecommunications base stations, large-capacity server racks, and industrial heat exchangers. Its high static pressure capability makes the 9EC2048P0J04 ideal for forcing air through dense filtration systems and tightly packed electronic components found in medical imaging equipment and CNC control cabinets, ensuring thermal stability in demanding environments.
