Description
The AVC DE07015B12U-A069 is a precision-engineered DC axial fan designed for high-density thermal management applications requiring substantial airflow in restricted spaces. Featuring a robust dual ball bearing architecture, this unit ensures minimized frictional coefficients and extended operational longevity under continuous high-speed loads. The aerodynamic impeller design optimizes static pressure delivery while maintaining structural rigidity, effectively reducing thermal impedance in compact enclosures. Integrated PWM speed control allows for dynamic modulation of rotational velocity, balancing acoustic performance with critical cooling requirements in sensitive electronic environments, making it an ideal solution for high-performance computing hardware.
Model Number: DE07015B12U-A069
Brand: AVC (Asia Vital Components)
Product Type: DC Axial Fan
Rated Voltage: 12 VDC
Rated Current: 0.70 A
Power Consumption: 8.40 W
Bearing Type: Dual Ball Bearing
Dimensions: 70 x 70 x 15 mm
Speed Control: PWM (Pulse Width Modulation)
Termination: 4-Wire Lead
Connector Type: Standard 4-Pin Motherboard Header
Housing Material: Thermoplastic PBT (UL94V-0)
Impeller Material: Thermoplastic PBT (UL94V-0)
Mounting Orientation: Any
Operating Temperature: -10°C to +70°C
Life Expectancy: 70,000 Hours @ 40°C
The DE07015B12U-A069 is specifically engineered for high-performance computing environments where space constraints and thermal density are critical factors. Commonly deployed in server rack chassis and compact industrial workstations, this unit provides the necessary airflow to dissipate heat from central processing units and power regulation modules. The DE07015B12U-A069 utilizes its PWM functionality to integrate seamlessly with motherboard logic, ensuring optimal cooling during peak processing loads while reducing energy consumption during idle states in telecommunications and medical instrumentation hardware.
Updated:
Additional information
| Shipping Weight | 1 kg |
|---|
