Description
Omron F03-20T 2-pole sensor terminator features a 10 VDC maximum detection signal, 1 W maximum power consumption, and supports up to 400 m maximum wiring distance. Engineered for integration with liquid leakage sensor amplifiers, this component utilizes an inter-electrode resistance detection method to ensure stable operation. The terminator is constructed to facilitate disconnection detection by maintaining a closed loop at the end of a sensing band, allowing the main amplifier to monitor circuit integrity. It operates in conjunction with 3-conductor VCT cables and features a compact form factor designed for panel space optimization.
F03-20T Specifications
Model: F03-20T
Brand: Omron
Product Category: Sensor Terminator / Fixed Terminal Block
Number of Poles: 2-Pole
Detection Signal Voltage: 10 VDC Max
Detection Signal Duration: 200 ms
Maximum Detection Time: 10 s Max
Maximum Wiring Distance: 400 m (Total cable and sensing band)
Compatible Amplifiers: K7L-AT50D, K7L-UD
Compatible Sensing Bands: F03-16PE, F03-16PT, F03-15, F03-16PS
Operating Temperature: -10 to 55 °C
Operating Humidity: 45% to 85% RH
Insulation Resistance: 10 MΩ at 100 VDC
Dielectric Strength: 1000 VAC at 50/60 Hz for 1 min
Power Consumption: 1 W Max
Response Time (Operate): 800 ms Max
Response Time (Release): 800 ms Max
Weight: 1.45 oz
F03-20T Applications
Primary applications include integration into industrial chemical processing plants, semiconductor manufacturing cleanrooms, and automated water management systems. Deployed within floatless level controller circuits and liquid leakage detection networks to provide continuous wire break monitoring across long-distance sensing bands.
