Description
The ebm-papst G1G170-AB31-03 is a precision-engineered EC centrifugal blower designed specifically for high-efficiency combustion applications and gas condensing technology. Utilizing advanced GreenTech EC motor technology, this unit delivers superior aerodynamic performance with optimized thermal impedance and reduced energy consumption compared to AC equivalents. The construction features a robust die-cast aluminum housing ensuring structural rigidity and effective heat dissipation, critical for high-temperature environments. Equipped with maintenance-free ball bearings, the G1G170-AB31-03 ensures long-term reliability under continuous operation. Its integrated electronics provide precise speed control via PWM or 0-10V interface, making it ideal for modulating gas condensing boilers where exact air-fuel ratios are critical for thermal efficiency and emissions control.
Model: G1G170-AB31-03
Brand: ebm-papst
Product Type: EC Centrifugal Gas Blower
Rated Voltage: 24VDC
Voltage Range: 16.0 – 28.0 VDC
Rated Power: 45 W
Rated Current: 2.1 A
Rated Speed: 4730 RPM
Max. Air Flow: 164.8 CFM (280 m³/h)
Max. Static Pressure: 4.01 inH₂O (1000 Pa)
Bearing Type: Ball Bearing
Motor Technology: EC (Electronically Commutated)
Speed Control: PWM / 0-10V Control Input
Tachometer Output: Yes
Housing Material: Die-cast Aluminum
Impeller Material: Sheet Steel, Hot-dip Galvanized
Insulation Class: Class F
Ingress Protection: IP20
Operating Temperature: -25°C to +60°C
Storage Temperature: -40°C to +80°C
Mounting Orientation: Any
Weight: 1.6 kg
Termination: Lead Wires
Certifications: CE, UL, CSA
Protection Features: Locked-rotor protection, Soft start, Reverse polarity protection
The G1G170-AB31-03 is specifically engineered for premix gas burners and condensing boiler systems requiring precise combustion air delivery. In residential and commercial heating sectors, the G1G170-AB31-03 ensures optimal fuel efficiency by modulating airflow to match burner demand dynamically. Additionally, this blower is utilized in fuel cell technology and specialized industrial process heating applications where compact, high-pressure air movement is mandatory for system stability.
