Description
The ebm-papst G2E120-DD70-22 is a high-performance single-inlet centrifugal blower designed for critical industrial air movement applications. Engineered with a robust external rotor AC motor, this unit offers superior aerodynamic efficiency and structural rigidity thanks to its precision die-cast aluminum housing. The forward-curved impeller design optimizes airflow while minimizing acoustic noise and turbulence, ensuring stable operation under significant static pressure. Featuring advanced thermal impedance management and a maintenance-free ball bearing architecture, the G2E120-DD70-22 delivers exceptional reliability and longevity. This blower is specifically calibrated for continuous duty cycles, making it an ideal solution for systems requiring consistent thermal dissipation and high-density air handling.
Model Number: G2E120-DD70-22
Brand: ebm-papst
Product Type: Centrifugal Blower (Single Inlet)
Rated Voltage: 230 VAC
Frequency: 50 Hz
Rated Current: 0.28 A
Power Input: 62 W
Rated Speed: 2350 RPM
Impeller Diameter: 120 mm
Max. Air Flow: 153 CFM (260 m³/h)
Max. Static Pressure: 1.12 inH₂O (280 Pa)
Bearing Type: Ball Bearing
Motor Type: External Rotor AC Motor (M2E068-BF)
Capacitor Requirement: 2.0 µF / 400 VDB
Housing Material: Die-cast aluminum
Impeller Material: Sheet steel, hot-dip galvanized
Insulation Class: B
Motor Protection: Thermal Overload Protector (TOP) wired internally
Operating Temperature: -25°C to +50°C
Mounting Orientation: Any
Direction of Rotation: Clockwise, seen on rotor
Termination: Lead wires
Weight: 2.2 kg
Compliance: CE, CCC
The G2E120-DD70-22 is widely deployed in industrial automation and electronic cooling sectors where space constraints and high pressure requirements coexist. Typical installations include control cabinet ventilation, server rack cooling systems, and heat dissipation for variable frequency drives. The G2E120-DD70-22 is also essential in medical devices and laboratory equipment, such as centrifuges and incubators, providing precise airflow control. Its rugged construction ensures durability in harsh manufacturing environments, effectively preventing thermal shutdowns in critical machinery and telecommunications infrastructure.
