Description
The ebm-papst G2E140-PI51-09 is a robust single-inlet centrifugal blower engineered for high-impedance industrial ventilation systems. Utilizing an advanced AC external rotor motor architecture, this unit delivers exceptional aerodynamic efficiency with a rated power output of 0.65kW. The design features a precision-balanced steel impeller housed within a durable scroll casing, ensuring structural rigidity and minimized vibration during operation. With a rotational speed range of 2050 to 2550 RPM, it optimizes thermal impedance management in critical cooling applications. The system is designed for continuous duty, leveraging high-grade ball bearings to maintain performance stability under demanding load conditions.
Model Number: G2E140-PI51-09
Alternate Model: RF2C-140/059
Brand: ebm-papst
Product Type: Centrifugal Blower (Single Inlet)
Rated Voltage: 230 VAC
Frequency: 50 / 60 Hz
Rated Power: 0.65 kW
Rated Speed: 2050 – 2550 RPM
Bearing Type: Ball Bearing
Impeller Diameter: 140 mm
Motor Technology: AC External Rotor
Material (Housing): Die-cast aluminum / Sheet steel
Material (Impeller): Sheet steel, hot-galvanized
Direction of Rotation: Clockwise (viewed toward rotor)
Insulation Class: Class B or F
Mounting Orientation: Any
Operating Temperature: -25 to +60 °C
Life Expectancy: > 40,000 hours (at 40°C)
Termination: Lead wires
Compliance: CE, RoHS
The G2E140-PI51-09 is specifically calibrated for integration into industrial environments requiring substantial static pressure, such as control cabinet cooling and server rack ventilation. Its high-power density makes it an ideal solution for heat dissipation in CNC machinery and telecommunications infrastructure where space is premium but airflow cannot be compromised. Engineers frequently deploy the G2E140-PI51-09 in medical device cooling systems and power supply units, relying on its consistent throughput to prevent thermal throttling in sensitive electronic components.
Updated:
Additional information
| Shipping Weight | 1 kg |
|---|
