Description
The Y.S.TECH NYW06025012BS is a high-performance DC Axial Fan engineered for demanding industrial thermal management applications. Featuring a robust Double Ball Bearing architecture, this unit ensures minimized friction and extended operational longevity under continuous load. The 12VDC motor assembly is calibrated for optimal torque, driving the impeller to deliver substantial airflow while maintaining structural rigidity. Designed with a focus on reducing thermal impedance in compact enclosures, the NYW06025012BS utilizes advanced aerodynamic blade geometry to maximize static pressure, making it an ideal solution for critical electronic cooling requirements where reliability is paramount.
Model Number: NYW06025012BS
Brand: Y.S.TECH
Product Type: DC Axial Fan
Rated Voltage: 12 VDC
Voltage Range: 7.0 – 13.2 VDC
Rated Current: 0.42 A
Input Power: 5.04 W
Rated Speed: 6800 RPM
Bearing Type: Double Ball Bearing
Max. Air Flow: 38.5 CFM (65.4 m³/h / 1.09 m³/min)
Max. Static Pressure: 14.5 mmH₂O (142 Pa / 0.57 inH₂O)
Dimensions: 60 x 60 x 25 mm
Weight: 65 g
Life Expectancy: 70,000 Hours at 40°C
Noise Level: 46.5 dBA
Housing Material: PBT (UL94V-0)
Impeller Material: PBT (UL94V-0)
Termination: 2-Wire Leads (+ Red, – Black)
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Ingress Protection: IP20
Safety Certifications: UL, CUL, TUV, CE
The NYW06025012BS is specifically configured for high-density electronic environments such as rack-mounted server chassis and telecommunications switching equipment. Its compact form factor allows for seamless integration into industrial automation controllers and power supply units where space is constrained but thermal loads are high. By delivering consistent forced convection, the NYW06025012BS effectively dissipates heat from sensitive components, ensuring system stability in CNC machinery and medical instrumentation.
