Description
The ebm-papst R2E225-BD92-09 is a high-efficiency backward curved Centrifugal Fan designed for demanding thermal management applications. Driven by the robust M2E068-DF AC motor, this unit features an aerodynamic impeller crafted from fiberglass-reinforced PA6 plastic, ensuring optimal structural rigidity and reduced rotational mass. The system utilizes precision ball bearings to minimize friction and extend operational lifespan under continuous load. Its advanced motor geometry optimizes thermal impedance, delivering consistent airflow performance while maintaining energy efficiency in industrial environments. This motorized impeller is engineered to provide superior static pressure capabilities relative to its compact footprint.
Model Number: R2E225-BD92-09
Brand: ebm-papst
Product Type: Backward Curved Centrifugal Fan / Motorized Impeller
Motor Model: M2E068-DF
Rated Voltage: 230 VAC
Frequency: 50 / 60 Hz
Voltage Range: 200 – 240 VAC
Rated Current: 0.38 / 0.51 A
Power Input: 85 / 115 W
Rated Speed: 2600 / 2700 RPM
Bearing Type: Ball Bearing
Max. Air Flow: 706.3 CFM (1200 m³/h / 20.0 m³/min)
Max. Static Pressure: 46.91 mmH₂O (460 Pa / 1.85 inH₂O)
Impeller Diameter: 225 mm
Impeller Material: PA6 Plastic, fiberglass-reinforced
Capacitor: 3.0 µF / 400 VDB
Insulation Class: F
Ingress Protection: IP44
Operating Temperature: -25 to +60 °C
Weight: 2.3 kg
Motor Protection: Thermal Overload Protector (TOP) wired internally
Number of Blades: 7
Direction of Rotation: Clockwise, seen on rotor
Compliance: CE, CCC
Mounting Position: Shaft horizontal or rotor on bottom; rotor on top on request
The R2E225-BD92-09 is engineered for critical ventilation tasks requiring high static pressure and reliable air movement. Commonly integrated into industrial air purification systems and large-scale disinfection cabinets, this motorized impeller ensures rapid heat dissipation and consistent air exchange. The R2E225-BD92-09 is also frequently utilized in electronics cooling, cabinet ventilation, and HVAC sub-assemblies where compact dimensions and high aerodynamic efficiency are paramount for system stability.
