Description
The ebm-papst RER190-39/14/2TDLOU-723 is a high-efficiency DC centrifugal fan engineered for critical industrial thermal management. Designed with a backward-curved motorized impeller, this unit delivers superior aerodynamic performance while maintaining structural rigidity under high-stress conditions. The motor architecture incorporates precision ball bearings and advanced commutation electronics to minimize thermal impedance and extend operational service life. Featuring a robust construction with an IP68 ingress protection rating, the fan is fully sealed against dust and continuous submersion in water, making it suitable for the most demanding environments. Its wide voltage input range and high power density ensure reliable airflow delivery in systems requiring consistent static pressure and rapid heat dissipation.
Model Number: RER190-39/14/2TDLOU-723
Brand: ebm-papst
Product Type: DC Centrifugal Fan / Motorized Impeller
Rated Voltage: 24 VDC
Voltage Range: 16.0 – 30.0 VDC
Rated Current: 2.42 A (2420 mA)
Power Consumption: 58 W
Impeller Diameter: 190 mm
Ingress Protection: IP68
Bearing Type: Ball Bearing
Motor Technology: Electronically Commutated (EC) DC
Direction of Airflow: Centrifugal
Impeller Material: Glass-fiber reinforced plastic (PA)
Housing Material: Die-cast Aluminum
Operating Temperature: -20°C to +70°C
Mounting Orientation: Any
Protection Class: III
Motor Protection: Reverse Polarity, Locked Rotor Protection
Application: Industrial Automation, Robotics
The RER190-39/14/2TDLOU-723 is specifically configured for integration into heavy-duty industrial automation systems, including KUKA robotics controllers and power supply units where reliability is non-negotiable. Its IP68 rating allows the RER190-39/14/2TDLOU-723 to operate effectively in outdoor telecommunications cabinets and CNC machinery exposed to coolants, ensuring critical components remain within safe thermal operating limits.
Updated:
Additional information
| Shipping Weight | 1 kg |
|---|
