SI-50 SI Marine 0-50PSU 20bar G1/2 Salinity Meter Electrode

Description

SI Marine SI-50 0 to 50 PSU 20 bar G 1/2″ Thread 316L Stainless Steel is a high-precision salinity electrode. The sensor body is constructed from corrosion-resistant 316L stainless steel and features an integrated Pt 100 resistance thermometer for real-time temperature compensation. It utilizes a four-electrode measurement principle to ensure stability and accuracy in high-conductivity marine environments. The unit is designed for continuous immersion with an IP 68 protection rating and a robust 4-pin electrical interface.

SI-50 Specifications
Model: SI-50
Brand: SI Marine
Category: Salinity Meter Electrode
Measurement Range: 0 to 50 PSU
Operating Temperature: 0 to 100 °C
Maximum Pressure: 20 bar
Body Material: 316L Stainless Steel
Electrode Material: Graphite
Process Connection: G 1/2″ Thread
Temperature Sensor: Pt 100
Accuracy: ± 0.5 % Full Scale
Protection Class: IP 68
Cable Connection: 4-pin Plug
Response Time: < 10 s

SI-50 Applications
Primary applications include integration into ballast water treatment systems (BWTS), marine engine cooling water monitoring, and desalination plant brine discharge control. Deployed within shipboard salinity monitoring consoles and offshore water quality analysis platforms.
