Description
The Delta TFA0412BN-YTA is a high-performance DC axial fan engineered for mission-critical thermal management in high-density server environments. Utilizing advanced DC brushless motor technology and a precision dual ball bearing architecture, this unit minimizes thermal impedance while maintaining exceptional structural rigidity under high-speed operation. The aerodynamic impeller design is optimized for high static pressure, ensuring effective airflow penetration through restrictive chassis and densely packed components. Its robust construction ensures reliability in continuous duty cycles, making it an ideal solution for demanding industrial cooling applications requiring superior heat dissipation.
Model Number: TFA0412BN-YTA
Brand: Delta Electronics
Product Type: DC Axial Fan
Rated Voltage: 12 VDC
Voltage Range: 7.0 – 13.2 VDC
Rated Current: 0.60 A
Power Consumption: 7.20 W
Rated Speed: 16000 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 26.50 CFM (45.02 m³/h / 0.75 m³/min)
Max. Static Pressure: 1.95 inH₂O (485.4 Pa / 49.5 mmH₂O)
Dimensions: 40 x 40 x 28 mm
Weight: 45 g
Life Expectancy: 70,000 Hours at 40°C
Noise Level: 56.0 dBA
Speed Control: PWM (Pulse Width Modulation)
Signal Output: Tachometer (Frequency Generator)
Ingress Protection: IP40
Insulation Class: Class A
Housing Material: PBT Plastic (UL94V-0)
Blade Material: PBT Plastic (UL94V-0)
Termination: 4-Wire Lead with Connector
Operating Temperature: -10 to +70 °C
Storage Temperature: -40 to +75 °C
Certifications: UL, cUL, TUV, CE
Protection: Locked Rotor Protection, Polarity Protection
The TFA0412BN-YTA is specifically designed for high-static pressure applications found in enterprise-grade hardware. Common deployments include 1U server racks, redundant power supply units, and high-performance networking switches where space is limited but cooling requirements are extreme. The TFA0412BN-YTA excels in forcing air through dense heatsinks and restricted enclosures, ensuring component stability in telecommunications equipment and industrial automation systems.
