Description
The Nidec U40R05MS1A7-57A07A is a precision-engineered DC axial fan designed for compact thermal management applications requiring high reliability and low acoustic noise. Featuring advanced brushless motor technology, this unit operates at a rated voltage of 5VDC with a highly efficient current draw of 0.08A, resulting in minimal power consumption. The 40x40x15mm chassis is constructed for structural rigidity, housing an aerodynamic impeller that optimizes airflow while maintaining static pressure in restricted enclosures. Equipped with a 4-wire interface, the fan supports Pulse Width Modulation (PWM) for dynamic speed regulation, allowing for precise thermal impedance matching based on real-time system load. This component is built to meet rigorous industrial standards, offering consistent performance in space-constrained electronic environments.
Model Number: U40R05MS1A7-57A07A
Brand: Nidec Corporation
Product Type: DC Axial Fan
OEM Part Number: X880927-004
Rated Voltage: 5 VDC
Rated Current: 0.08 A
Input Power: 0.40 W
Dimensions: 40 x 40 x 15 mm
Termination: 4-Wire Lead
Connector Type: Proprietary 4-Pin
Speed Control: PWM (Pulse Width Modulation)
Bearing Type: Hydro Dynamic Bearing
Mounting Orientation: Flange Mount
Housing Material: PBT Plastic (UL94V-0)
Application: Xbox One Kinect 2.0 Replacement
The U40R05MS1A7-57A07A is the designated cooling solution for the Microsoft Xbox One Kinect 2.0 motion sensor array, ensuring critical components remain within safe operating temperatures during extended operation. Its compact form factor allows for seamless integration into the Kinect’s dense internal architecture, effectively dissipating heat from the depth sensors and camera modules. Beyond this specific OEM application, the U40R05MS1A7-57A07A is well-suited for small form factor (SFF) PCs, 3D printer controller cooling, and other embedded electronics requiring 5V PWM-controlled airflow. Technicians utilizing the U40R05MS1A7-57A07A benefit from its precise speed control and low-vibration operation, making it an excellent choice for noise-sensitive equipment.
