Description
The NMB 11925SA-24M-BL-1 is a precision-engineered DC Axial Fan designed for industrial thermal management and electronic cooling applications. Manufactured by MinebeaMitsumi, this unit features a robust Dual Ball Bearing system that ensures reduced friction coefficient and extended operational longevity under continuous loads. The aerodynamic impeller design optimizes airflow while maintaining a low acoustic profile, making it suitable for noise-sensitive environments. With a 24VDC operating voltage and integrated 3-wire tachometer signal output, it provides reliable speed monitoring and efficient heat dissipation. The housing utilizes reinforced PBT plastic to ensure structural rigidity and thermal stability, minimizing vibration during operation.
Model Number: 11925SA-24M-BL-1
Brand: NMB (MinebeaMitsumi)
Product Type: DC Axial Fan
Rated Voltage: 24 VDC
Voltage Range: 14.0 – 27.6 VDC
Rated Current: 0.12 A
Power Consumption: 2.88 W
Rated Speed: 1800 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 68.0 CFM (115.5 m³/h / 1.92 m³/min)
Max. Static Pressure: 4.5 mmH₂O (44.1 Pa / 0.18 inH₂O)
Dimensions: 120 x 120 x 25 mm
Termination: 3-Wire Leads with Tachometer Sensor
Housing Material: Reinforced PBT Plastic (UL94V-0)
Blade Material: Reinforced PBT Plastic (UL94V-0)
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Noise Level: 34.0 dBA
Life Expectancy: 60,000 Hours @ 25°C
Origin: Cambodia
Condition: New Original
The 11925SA-24M-BL-1 is engineered for critical cooling applications requiring consistent airflow and durability. Common deployments include server cabinet ventilation, industrial automation control panels, and power supply cooling where thermal reliability is paramount. The 11925SA-24M-BL-1 integrates seamlessly into existing 24V systems, providing efficient heat extraction for telecommunications equipment and medical instrumentation, ensuring components remain within safe operating temperature ranges.
