Description
The NMB-MAT 2410ML-07W-B49-G01 is a precision-engineered Axial Fan designed for high-reliability industrial cooling applications. Utilizing NMB’s proprietary dual ball bearing architecture, this unit ensures minimal friction and extended operational longevity under continuous load. The 48VDC motor features an optimized electromagnetic design to deliver consistent torque while maintaining low thermal impedance. Its aerodynamic impeller geometry balances static pressure and airflow, making it suitable for dense electronic enclosures. Constructed with structural rigidity in mind, the frame resists vibration, ensuring stable performance in telecommunications and switching equipment environments. The unit includes a tachometer signal for real-time speed monitoring, essential for active thermal management systems.
Model Number: 2410ML-07W-B49-G01
Brand: NMB-MAT (MinebeaMitsumi)
Product Type: Axial Fan
Rated Voltage: 48 VDC
Voltage Range: 28.0 – 56.0 VDC
Rated Current: 0.07 A
Power: 3.36 W
Rated Speed: 4600 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 23.3 CFM (39.6 m³/h / 0.66 m³/min)
Max. Static Pressure: 5.4 mmH₂O (52.9 Pa / 0.21 inH₂O)
Dimensions: 60 x 60 x 25 mm
Weight: 65 g
Life Expectancy: 100,000 Hours @ 25°C
Noise Level: 35.0 dB(A)
Housing Material: Plastic (UL94V-0)
Impeller Material: Plastic (UL94V-0)
Termination: 3-Wire (Lead Wire)
Sensor Output: Tachometer (Speed Sensor)
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Ingress Protection: IP20
Mounting Orientation: Any
Designed for critical thermal management, the 2410ML-07W-B49-G01 excels in telecommunications infrastructure, specifically within network switches and server rack modules where continuous uptime is mandatory. The compact 60mm footprint allows for seamless integration into power supply units (PSUs) and industrial automation control panels. By maintaining optimal operating temperatures, the 2410ML-07W-B49-G01 prevents thermal throttling in sensitive electronic components, ensuring system stability in medical instrumentation and CNC machinery control systems.
