Description
The Sanyo Denki 9CRA0812P8G036 is a specialized high-static pressure air mover belonging to the San Ace 80 CR (Counter Rotating) series. Designed for systems with high impedance, this unit features a dual-motor architecture with contra-rotating impellers that straighten airflow and significantly boost static pressure capabilities compared to single-stage counterparts. The 80x80x80mm chassis is constructed from flame-retardant plastics and houses precision dual ball bearings, ensuring structural rigidity and long-term operational stability under high-speed rotation. Engineered with a 12VDC drive system and PWM control capabilities, it delivers exceptional thermal management performance, optimizing the balance between aerodynamic efficiency and power consumption in critical industrial applications.
Model Number: 9CRA0812P8G036
Brand: Sanyo Denki
Product Type: Counter Rotating Axial Fan
Series: San Ace 80 CR
Rated Voltage: 12VDC
Voltage Range: 10.8 – 13.2 VDC
Rated Current: 5.3 A
Power: 63.6 W
Rated Speed: 10500 / 9500 RPM (Inlet/Outlet)
Bearing Type: Dual Ball Bearing
Max. Air Flow: 187.0 CFM (317.7 m³/h / 5.29 m³/min)
Max. Static Pressure: 96.5 mmH₂O (946 Pa / 3.80 inH₂O)
Dimensions: 80x80x80mm
Weight: 450 g
Frame Material: Plastics (UL94V-0)
Impeller Material: Plastics (UL94V-0)
Speed Control: PWM Control
Ingress Protection: IP54 (Optional)
Operating Temperature: -10 to +70°C
Storage Temperature: -30 to +70°C
Life Expectancy: 40,000 Hours (at 60°C)
Termination: Lead Wires
Motor Protection: Locked Rotor Protection, Reverse Polarity Protection
The 9CRA0812P8G036 is specifically engineered for high-density applications where back pressure is a significant challenge, such as automotive turbocharging auxiliary cooling and tightly packed server racks. Its ability to maintain high airflow against resistance makes the 9CRA0812P8G036 an ideal solution for telecommunications base stations, industrial controllers, and power supply units requiring forced air induction to prevent thermal throttling.
