A20B-8201-0541 Fanuc 24VDC 30i/31i/32i Series CNC Control Board

Description

Fanuc A20B-8201-0541 is a high-performance CNC control board featuring a 200 mm x 150 mm multi-layer PCB architecture designed for 24 VDC nominal operation within the 30i, 31i, and 32i series systems. The hardware incorporates high-density surface-mount components, integrated HSSB (High-Speed Serial Bus) communication interfaces, and fiber-optic port connectivity for low-latency data transmission. The board utilizes a rigid FR-4 substrate with gold-plated contact points to ensure signal integrity across complex logic circuits and high-speed processing units.

A20B-8201-0541 Specifications
Model: A20B-8201-0541
Brand: Fanuc
Category: CNC Main Control Board
Compatible Series: 30i, 31i, 32i Model A/B, R-30iB Mate
Input Voltage: 24 VDC
PCB Type: Multi-layer Rigid FR-4
Interface Type: HSSB (High-Speed Serial Bus)
Communication: Fiber Optic / I/O Link
Dimensions: 200 mm x 150 mm x 25 mm
Weight: 0.45 kg
Operating Temperature: 0 to 55 °C
Storage Temperature: -20 to 75 °C
Humidity: 10 to 90 % RH (non-condensing)
Mounting: Slot-in Chassis Mount
Component Technology: Surface Mount (SMT)
Certifications: CE, UL, RoHS

A20B-8201-0541 Applications
Primary applications include integration into Fanuc 30i-B series CNC controllers, multi-axis machining center logic units, and high-precision lathe automation systems. Deployed within industrial robotic control cabinets and complex milling machine synchronization modules for real-time motion command processing.
