Description
The Delta AFB1548EH-C-SP12 is a precision-engineered DC Axial Fan designed for high-static pressure industrial environments. Utilizing advanced aerodynamic blade geometry and a durable Two Ball Bearing system, this unit optimizes thermal impedance reduction while maintaining structural rigidity under high-speed operation. The 48VDC motor integrates sophisticated commutation electronics to ensure consistent torque delivery and longevity. Its slim profile allows for efficient integration into space-constrained enclosures, delivering robust airflow performance essential for critical thermal management in demanding electromechanical systems.
Model Number: AFB1548EH-C-SP12
Brand: Delta Electronics
Product Type: DC Axial Fan
Rated Voltage: 48 VDC
Voltage Range: 28.0 – 56.0 VDC
Rated Current: 1.50 A
Power: 72.0 W
Rated Speed: 4800 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 260.5 CFM (442.6 m³/h / 7.37 m³/min)
Max. Static Pressure: 22.5 mmH₂O (220.6 Pa / 0.88 inH₂O)
Dimensions: 172 x 150 x 25.4 mm
Weight: 350 g
Life Expectancy: 70,000 Hours @ 40°C
Noise Level: 62.5 dB-A
Speed Control: PWM / Tachometer (4-Wire)
Frame Material: Aluminum Die-Cast / PBT
Blade Material: Thermoplastic PBT (UL94V-0)
Ingress Protection: IP55
Insulation Class: Class A
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +75°C
Termination: 4-Wire Lead with Connector
Mounting Orientation: Any
Safety Protection: Locked Rotor, Polarity Protection
Engineered for rigorous duty cycles, the AFB1548EH-C-SP12 is ideally suited for industrial control chassis and high-density server rack cooling solutions where space is at a premium. The slim form factor allows the AFB1548EH-C-SP12 to be mounted in tight clearance areas within telecommunications equipment and power supply units, ensuring rapid heat dissipation for sensitive electronic components.
