Description
The Nidec D03X-05TM is a precision-engineered micro axial fan designed for high-density electronic environments requiring efficient thermal management. Operating at a rated voltage of 5VDC with a current draw of 0.12A, this 30mm cooling solution integrates Nidec’s advanced motor technology to deliver consistent airflow while minimizing vibrational noise. The unit features a compact 30x30x10mm frame constructed for structural rigidity, ensuring optimal performance in restricted spaces. Engineered for reliability, the D03X-05TM utilizes a specialized bearing system to reduce friction and extend operational lifespan, making it an ideal component for maintaining thermal equilibrium in sensitive micro-electronics and hard drive enclosures.
Model Number: D03X-05TM
Brand: Nidec
Product Type: Micro Axial Fan
Rated Voltage: 5VDC
Operating Voltage Range: 4.5 – 5.5 VDC
Rated Current: 0.12 A
Input Power: 0.60 W
Rated Speed: 9000 RPM (Nominal)
Max. Air Flow: 3.5 CFM (5.9 m³/h)
Max. Static Pressure: 3.2 mmH₂O (31 Pa)
Dimensions: 30 x 30 x 10 mm
Bearing Type: Precision Sleeve / Hydro
Noise Level: 24.0 dBA
Termination: 2-Wire Lead
Connector: 2-Pin Micro Connector
Housing Material: PBT (UL94V-0)
Impeller Material: PBT (UL94V-0)
Mounting Orientation: Any
Operating Temperature: -10°C to +70°C
Application: Hard Drive Enclosure Cooling
Weight: 8.0 g
The D03X-05TM is specifically engineered for compact thermal applications where space is at a premium. It is widely utilized in external micro hard drive enclosures to prevent thermal throttling during data transfer operations. Additionally, the D03X-05TM serves as a critical cooling component in small form factor (SFF) PCs, embedded systems, and portable instrumentation. Its low power consumption and compact footprint make the D03X-05TM suitable for handheld medical devices and precision optical equipment requiring active cooling without significant bulk.
