Description
The Nidec G75G24MS1ZZ-53J25 is a precision-engineered centrifugal blower fan designed for high-static pressure applications where directed airflow is critical. Utilizing advanced DC motor technology, this unit optimizes thermal impedance management within compact enclosures, ensuring efficient heat dissipation for sensitive electronics. The aerodynamic volute design minimizes turbulence while maximizing air velocity, making it an ideal solution for overcoming high system resistance found in projection equipment and dense industrial chassis. Constructed with structural rigidity in mind, the housing maintains dimensional stability under thermal stress. This specific model features a specialized 25VDC winding configuration, tailored for specific industrial or projection equipment requirements, delivering reliable performance with a balanced current draw of 0.14A and integrated speed monitoring capabilities via its 3-wire interface.
Model Number: G75G24MS1ZZ-53J25
Brand: Nidec
Product Type: Centrifugal Blower Fan
Rated Voltage: 25V DC
Rated Current: 0.14 A
Power Consumption: 3.5 W
Dimensions: 75 x 75 x 20 mm
Termination: 3-Wire Lead
Wire Length: 190 mm
Connector Type: 3-Pin Header
Motor Type: DC Brushless
Airflow Direction: 90 Degree (Radial)
Housing Material: Industrial Grade Plastic
Mounting Style: Flange Mount
Speed Control: Tachometer Output (3rd Wire)
Application: Projector Cooling / Turbo Blower
The G75G24MS1ZZ-53J25 is specifically engineered for integration into high-performance projection systems where concentrated airflow is required to cool high-intensity lamps and optical components. Beyond projection technology, this blower is suitable for compact industrial electronics, small form-factor servers, and telecommunications equipment requiring directed cooling in tight spaces. The G75G24MS1ZZ-53J25 excels in environments where standard axial fans cannot generate sufficient static pressure to penetrate dense heatsinks or restricted airflow paths, ensuring critical components remain within safe operating temperature ranges.
Updated:
Additional information
| Shipping Weight | 1 kg |
|---|
