Description
The SUNON KD1212PTB1-6A is a precision-engineered DC axial fan designed for critical thermal management in industrial and computing environments. Utilizing advanced brushless DC motor technology and a robust double ball bearing architecture, this unit ensures exceptional longevity and structural rigidity under continuous operation. The aerodynamic impeller design optimizes airflow efficiency while minimizing turbulence, resulting in a favorable ratio of static pressure to noise. With a power rating of 4.8W, the KD1212PTB1-6A effectively mitigates thermal impedance in high-density enclosures, maintaining system stability through reliable forced convection cooling.
Model Number: KD1212PTB1-6A
Brand: SUNON
Product Type: DC Axial Fan
Rated Voltage: 12 VDC
Voltage Range: 10.2 – 13.8 VDC
Rated Current: 0.40 A
Power Consumption: 4.8 W
Rated Speed: 3100 RPM
Bearing Type: Double Ball Bearing
Max. Air Flow: 90.0 CFM (152.9 m³/h / 2.55 m³/min)
Max. Static Pressure: 0.28 inH₂O (69.7 Pa / 7.11 mmH₂O)
Dimensions: 120 x 120 x 25 mm
Weight: 200 g
Life Expectancy: 70,000 Hours at 40°C
Noise Level: 44.5 dB(A)
Frame Material: Thermoplastic PBT (UL94V-0)
Blade Material: Thermoplastic PBT (UL94V-0)
Termination: 2-Wire Lead
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Ingress Protection: IP20
Safety Certifications: UL, CUR, TUV
Motor Protection: Impedance Protected; Reverse Polarity Protection
This cooling solution is specifically calibrated for integration into server racks, telecommunications cabinets, and industrial automation enclosures. The KD1212PTB1-6A provides the necessary airflow to dissipate heat from power supplies and sensitive electronic components within confined chassis spaces. By installing the KD1212PTB1-6A, operators ensure consistent thermal regulation in CNC machinery and network switchgear, preventing overheating-induced failures in mission-critical hardware.
