Description
The Protechnic MGT4012XB-O20 is a precision-engineered DC Axial Fan designed for high-density thermal management in server and industrial electronics. Utilizing advanced aerodynamic impeller geometry and a robust Dual Ball Bearing architecture, this unit minimizes thermal impedance while maintaining exceptional structural rigidity under continuous load. The motor assembly features high-torque stator windings optimized for 12VDC operation, ensuring stable rotational velocities and efficient heat dissipation. Engineered for reliability, the fan incorporates UL94V-0 rated thermoplastic housing to withstand elevated operating temperatures, making it a critical component for systems requiring consistent airflow and long-term durability.
Model Number: MGT4012XB-O20
Brand: Protechnic Electric
Product Type: DC Axial Fan
Rated Voltage: 12VDC
Voltage Range: 7.0 – 13.2 VDC
Rated Current: 0.15 A
Power Consumption: 1.80 W
Rated Speed: 6500 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 7.20 CFM (12.23 m³/h / 0.20 m³/min)
Max. Static Pressure: 3.56 mmH₂O (34.88 Pa / 0.14 inH₂O)
Dimensions: 40x40x10mm
Weight: 18.0 g
Life Expectancy: 70,000 Hours at 40°C
Noise Level: 28.0 dB(A)
Housing Material: Glass Fiber Reinforced PBT (UL94V-0)
Impeller Material: Glass Fiber Reinforced PBT (UL94V-0)
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Termination: 2-Wire Lead (Red +, Black -)
Ingress Protection: IP40
Certifications: CE, UL, TUV, RoHS
The MGT4012XB-O20 is specifically calibrated for compact industrial and IT infrastructure applications, including 1U server racks, network switches, and RAID storage arrays. Its low-profile 10mm thickness allows for seamless integration into space-constrained enclosures where airflow channels are narrow. Beyond IT hardware, the MGT4012XB-O20 is frequently deployed in medical instrumentation and embedded industrial automation controllers, providing necessary active cooling to prevent component throttling and ensure system stability.
