Description
The ORIX MR18-DC is a robust industrial Axial Fan engineered by Oriental Motor to deliver superior airflow in high-static pressure environments. This unit features a precision-balanced motor assembly housed within a high-rigidity aluminum die-cast frame, ensuring minimal vibration and exceptional structural integrity under thermal stress. The aerodynamic impeller design optimizes the P-Q curve to reduce thermal impedance in dense electronic enclosures. Utilizing advanced ball bearing technology, the motor ensures long-term reliability and consistent performance, making it an ideal solution for critical cooling applications requiring continuous duty cycles.
Model Number: MR18-DC
Brand: ORIX (Oriental Motor)
Product Type: Axial Fan
Rated Voltage: 24 VDC
Voltage Range: 20.4 – 27.6 VDC
Rated Current: 1.4 A
Power: 33.6 W
Rated Speed: 3200 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 230.0 CFM (390.7 m³/h / 6.51 m³/min)
Max. Static Pressure: 18.5 mmH₂O (181.4 Pa / 0.73 inH₂O)
Dimensions: 180 x 180 x 90 mm
Weight: 1.7 kg
Life Expectancy: 60,000 Hours at 40°C
Noise Level: 58 dB(A)
Housing Material: Aluminum Die-Cast
Blade Material: Polycarbonate (UL94V-0)
Ingress Protection: IP20
Insulation Class: Class E
Operating Temperature: -10°C to +60°C
Storage Temperature: -20°C to +70°C
Termination: Lead Wires
Mounting Orientation: Any
Motor Protection: Locked Rotor Protection, Reverse Polarity Protection
Origin: Japan
The MR18-DC is specifically designed for large-scale industrial machinery and ventilation systems where reliability is paramount. Common deployment scenarios include cooling large variable frequency drives (VFDs), server cabinet ventilation, and heat dissipation in CNC control panels. The high airflow capacity of the MR18-DC ensures rapid thermal exchange in telecommunications infrastructure and power supply units, effectively preventing overheating in continuous-operation environments.
