Description
The Rittal SK 3325.107 is a high-efficiency TopTherm fan-and-filter unit designed for optimal thermal management in industrial enclosures. Utilizing advanced diagonal fan technology, this unit ensures stable pressure build-up and consistent airflow distribution, significantly reducing thermal impedance within high-density server racks and control cabinets. The system features a tool-free assembly mechanism for rapid installation and maintenance, while the robust housing ensures structural rigidity. Engineered for continuous operation, the motor integrates self-starting shaded pole technology, providing reliable cooling performance under varying load conditions while maintaining strict adherence to IP54 protection standards.
Model Number: SK 3325.107
Brand: Rittal
Product Type: TopTherm Fan-and-filter Unit
Rated Voltage: 230 VAC
Frequency: 50/60 Hz
Air Throughput (Unimpeded): 230 m³/h (50Hz) / 250 m³/h (60Hz)
Air Throughput (With Filter Mat): 183 m³/h (50Hz) / 217 m³/h (60Hz)
Rated Power: 41 W (50Hz) / 38 W (60Hz)
Rated Current: 0.19 A (50Hz) / 0.18 A (60Hz)
Dimensions: 255 x 255 mm
Installation Depth: 107 mm
Mounting Cut-out: 224 x 224 mm
Build Depth: 25 mm
Fan Type: Diagonal, Shaded Pole Motor
Bearing Type: Ball Bearing
Noise Level: 49 dB(A) (50Hz) / 55 dB(A) (60Hz)
Ingress Protection: IP54 (Standard) / IP55 (With Hose-proof Hood)
Operating Temperature: -30°C to +55°C
Storage Temperature: -30°C to +70°C
Service Life: 60,000 Hours (at 25°C)
Color: RAL 7035 (Light Grey)
Pre-fuse: Miniature Circuit-Breaker/Fuse: 4 A
Mounting Type: Snap-in (Tool-free)
Filter Material: Chemical Fibre Mat
Certification: UL, cUL, CSA, CE, EAC
The SK 3325.107 is engineered for critical thermal regulation in industrial automation and IT infrastructure. Commonly deployed in electrical control panels, the SK 3325.107 prevents heat accumulation in server racks and telecommunication enclosures, ensuring component longevity. Its robust filtration system makes it ideal for manufacturing environments where dust ingress poses a risk to sensitive electronics, such as CNC machinery controls and power distribution units.
