Description
The Delta THD0948HE-ABGA is a high-performance Axial Fan engineering for mission-critical thermal management in demanding environments. Utilizing advanced DC brushless motor technology paired with a precision dual ball bearing architecture, this unit minimizes thermal impedance while maintaining exceptional structural rigidity. The aerodynamic impeller design is optimized to deliver superior static pressure, ensuring efficient heat dissipation in dense electronic enclosures and high-resistance systems.
Model Number: THD0948HE-ABGA
Brand: Delta Electronics
Product Type: Axial Fan
Rated Voltage: 48VDC
Voltage Range: 36.0 – 56.0 VDC
Rated Current: 1.50A
Power: 72.0 W
Rated Speed: 7400 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 160.2 CFM (272.1 m³/h / 4.53 m³/min)
Max. Static Pressure: 38.5 mmH₂O (377.5 Pa / 1.51 inH₂O)
Dimensions: 92x92x38mm
Weight: 295 g
Life Expectancy: 70000 hrs at 40°C
Speed Control: PWM
Ingress Protection: IP68 (Waterproof/Potting)
Noise Level: 69.5 dB-A
Insulation Class: Class A
Housing Material: PBT Plastic (UL94V-0)
Impeller Material: PBT Plastic (UL94V-0)
Termination: 4-Wire Leads
Operating Temperature: -10°C ~ +70°C
Safety Protection: Locked Rotor, Polarity Protection
Designed for rigorous industrial applications, theTHD0948HE-ABGA excels in scenarios requiring high-velocity airflow and resistance to environmental contaminants. It is ideally suited for high-density server racks, outdoor telecommunications cabinetry, and cooling for heavy-duty CNC machinery where fluid exposure is a risk. The waterproof capabilities of the THD0948HE-ABGA make it a robust solution for marine electronics and ruggedized industrial power supplies.
