Description
The Nidec V80E14MS2A3-57A611 is a specialized DC Axial Fan engineered for the rigorous thermal demands of refrigeration and cold-chain storage systems. Operating at a specific nominal voltage of 13.6VDC, this unit integrates advanced DC brushless motor technology with a precision bearing architecture designed to withstand low-temperature environments while maintaining structural rigidity. The aerodynamic impeller profile is optimized to deliver consistent airflow against the high static pressure resistance often found in evaporator chambers and frosted heat exchangers. Its robust construction ensures minimal thermal impedance and reliable operation, making it a critical component for maintaining thermal equilibrium in appliance and industrial cooling circuits.
Model Number: V80E14MS2A3-57A611
Brand: Nidec
Product Type: DC Axial Fan
Rated Voltage: 13.6 VDC
Voltage Range: 12.0 – 14.5 VDC
Dimensions: 80 x 80 x 38 mm
Bearing Type: Precision Ball Bearing
Motor Type: DC Brushless
Air Flow Direction: Axial
Housing Material: Reinforced Plastic (UL94V-0)
Blade Material: Reinforced Plastic
Termination: 3-Wire Lead with Connector
Speed Control: Tachometer Output (Sensor)
Operating Temperature: -10°C to +70°C
Application: Refrigerator Evaporator Cooling
Mounting: Flange Mount
Ingress Protection: Moisture Resistant Design
The V80E14MS2A3-57A611 is primarily utilized in residential and commercial refrigeration units, specifically functioning as an evaporator fan to circulate cold air throughout the compartment. Beyond standard kitchen appliances, the V80E14MS2A3-57A611 is suitable for wine coolers, medical vaccine fridges, and compact heat exchange systems requiring a specific 13.6V input. Its moisture-resistant design ensures longevity in high-humidity zones within server cooling backups or specialized CNC control cabinets where condensation might occur.
