Description
The Xiangyu XY-6025B2H is a specialized EC Axial Fan designed for high-efficiency thermal management in compact industrial environments. Integrating advanced Electronic Commutation (EC) technology, this unit accepts a wide AC voltage input range while delivering the energy efficiency typically associated with DC motors. The 60mm frame houses a precision-engineered impeller optimized for reducing thermal impedance while maintaining significant static pressure. Built with structural rigidity and durable bearing architecture, it ensures reliable operation under continuous duty cycles. This cooling solution is engineered to minimize electromagnetic interference, making it ideal for sensitive electronic enclosures and refrigeration systems requiring consistent airflow and longevity.
Model Number: XY-6025B2H
Brand: Xiangyu
Product Type: EC Axial Fan
Rated Voltage: 110-240 VAC
Voltage Range: 110 – 240 VAC
Frequency: 50/60 Hz
Rated Current: 0.05 A
Power: 3.5 W
Rated Speed: 4800 RPM
Bearing Type: Ball Bearing
Max. Air Flow: 22.5 CFM (38.2 m³/h)
Max. Static Pressure: 5.2 mmH₂O (51 Pa)
Dimensions: 60 x 60 x 25 mm
Weight: 0.06 kg
Life Expectancy: 50,000 Hours at 25°C
Speed Control: Fixed Speed
Ingress Protection: IP20
Noise Level: 34 dBA
Housing Material: Thermoplastic PBT (UL94V-0)
Termination: 2-Wire Leads
Operating Temperature: -10°C to +70°C
Mounting Orientation: Any
Certifications: CE, RoHS
The XY-6025B2H is engineered for critical cooling applications within the commercial refrigeration and industrial appliance sectors. Specifically suited for maintaining optimal temperatures in refrigerators, freezers, and display cabinets, this unit effectively dissipates heat from condensers and electronic control modules. The XY-6025B2H provides consistent airflow required for continuous operation in beverage coolers and medical cold storage units, ensuring equipment longevity and thermal stability in confined installation spaces.
