Description
The YCCFAN YBD4015B24 is a precision-engineered DC Blower Fan designed for high-density thermal management applications requiring concentrated airflow. Utilizing advanced brushless DC motor technology, this unit ensures consistent torque delivery and minimized electromagnetic interference, essential for sensitive electronic environments. The architecture features a robust dual ball bearing system, significantly enhancing longevity and reducing frictional coefficients under continuous high-speed operation. Its aerodynamic centrifugal impeller design is optimized to maximize static pressure while maintaining manageable noise levels, effectively overcoming high thermal impedance in restricted enclosures. Constructed with high-grade thermoplastic materials for structural rigidity, the YBD4015B24 delivers reliable cooling performance, making it an integral component for maintaining optimal operating temperatures in critical industrial assemblies.
Model Number: YBD4015B24
Brand: YCCFAN
Product Type: DC Brushless Blower
Rated Voltage: 24VDC
Voltage Range: 14.0 – 27.6 VDC
Rated Current: 0.35 A
Power Consumption: 8.40 W
Rated Speed: 8500 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 4.50 CFM (7.65 m³/h / 0.12 m³/min)
Max. Static Pressure: 20.3 mmH₂O (199 Pa / 0.80 inH₂O)
Dimensions: 40 x 40 x 15 mm
Noise Level: 45.0 dBA
Termination: 3-Wire Leads
Speed Control: Tachometer Output
Housing Material: PBT Plastic (UL94V-0)
Blade Material: PBT Plastic (UL94V-0)
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Life Expectancy: 50,000 Hours at 40°C
Mounting Orientation: Any
The YBD4015B24 is specifically engineered for compact industrial and IT environments where directed airflow is critical for system stability. Common deployment scenarios include rack-mounted server cooling modules and telecommunications equipment where high static pressure is required to force air through dense heatsinks or restricted ducts. Additionally, the YBD4015B24 is frequently utilized in industrial control units, CNC machinery electronics, and precision medical devices such as humidifiers, ensuring reliable thermal regulation in space-constrained chassis.
