Description
The NMB 06025SS-24N-AL-D3 is a precision-engineered axial cooling fan designed for high-reliability industrial electronics. Utilizing NMB’s advanced motor technology, this unit delivers consistent airflow with optimized thermal impedance management. The 60mm chassis houses a robust bearing system designed to withstand continuous operation in demanding environments, ensuring structural rigidity and minimal vibration. Its aerodynamic impeller design maximizes static pressure while maintaining acoustic efficiency. Specifically calibrated for variable frequency drives and servo systems, this DC fan integrates a locked rotor alarm signal for critical system monitoring, making it an essential component for thermal regulation in automation hardware.
Model Number: 06025SS-24N-AL-D3
Brand: NMB-MAT (MinebeaMitsumi)
Product Type: Axial Fan
Rated Voltage: 24VDC
Operating Voltage Range: 14.0 – 27.6 VDC
Rated Current: 0.11 A
Input Power: 2.64 W
Rated Speed: 4500 RPM
Max. Air Flow: 23.5 CFM (39.9 m³/h / 0.66 m³/min)
Max. Static Pressure: 5.2 mmH₂O (51.0 Pa / 0.20 inH₂O)
Noise Level: 34.0 dB-A
Dimensions: 60x60x25mm
Bearing Type: Dual Ball Bearing
Termination: 3-Wire Leads
Sensor Type: Alarm Signal (Locked Rotor Output)
Housing Material: PBT (UL94V-0)
Impeller Material: PBT (UL94V-0)
Operating Temperature: -10°C to +70°C
Life Expectancy: 60,000 Hours @ 40°C
Ingress Protection: IP20
Application: Schneider Inverter / Yaskawa Driver
Designed primarily for thermal management in industrial automation, the 06025SS-24N-AL-D3 serves as a critical cooling component for Schneider variable frequency drives (VFDs) and Yaskawa servo drivers. Its compact 60mm footprint allows for seamless integration into high-density control cabinets and power supply units where space is at a premium. The 06025SS-24N-AL-D3 ensures reliable heat dissipation for sensitive power electronics, preventing thermal throttling in CNC machinery, robotic controllers, and telecommunications equipment racks.
