Description
The NMB 09225SS-12N-AU-D1 is a DC axial fan engineered for high-efficiency thermal management in precision electronics. Utilizing advanced motor commutation circuitry and a specialized sleeve bearing architecture, this unit minimizes thermal impedance while maintaining structural rigidity under continuous operation. The aerodynamic impeller design is optimized to reduce turbulence and acoustic output, ensuring stable airflow delivery. This model features a 4-wire configuration, enabling sophisticated speed control and system monitoring for mission-critical cooling requirements where reliability and precise thermal regulation are paramount.
Model Number: 09225SS-12N-AU-D1
Brand: NMB-MAT (MinebeaMitsumi)
Product Type: DC Axial Fan
Rated Voltage: 12VDC
Voltage Range: 7.0 – 13.8 VDC
Rated Current: 0.24A
Power: 2.88W
Rated Speed: 3200 RPM
Bearing Type: Sleeve Bearing
Max. Air Flow: 52.9 CFM (1.50 m³/min)
Max. Static Pressure: 4.2 mmH₂O (41.2 Pa)
Dimensions: 92x92x25mm
Weight: 95g
Life Expectancy: 40,000 Hours at 25°C
Speed Control: PWM (Pulse Width Modulation)
Monitoring Output: Tachometer / Frequency Generator
Noise Level: 36.0 dBA
Housing Material: Plastic (UL94V-0)
Blade Material: Plastic (UL94V-0)
Termination: 4-Lead Wires
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Protection Features: Locked Rotor Protection, Reverse Polarity Protection
Insulation Resistance: 10M Ohm min. at 500VDC
The 09225SS-12N-AU-D1 is specifically designed for integration into high-end projection systems and digital imaging equipment where precise temperature control is required. Given its 4-wire PWM capabilities, the 09225SS-12N-AU-D1 excels in server enclosures, medical diagnostic tools, and telecommunications hardware that demand dynamic cooling profiles. Its compact 92mm form factor allows for versatile mounting in industrial workstations and CNC control cabinets, providing consistent airflow to sensitive internal components.
