12038FB-A1N-WPD-1 NMB 115VAC 17W 119mm AC Axial Fan

Description

NMB 12038FB-A1N-WPD-1 119 x 119 x 38 mm 115 VAC 17 W 105 CFM is a high-performance cooling unit featuring a die-cast aluminum housing and a UL 94V-0 reinforced plastic impeller. It utilizes a high-precision dual ball bearing system for extended operational life and is driven by a shaded pole induction motor. The electrical interface consists of lead wire terminations, and the motor is impedance protected against thermal overload. The design incorporates a specific WPD suffix indicating environmental protection or specialized wiring configurations for industrial integration.

12038FB-A1N-WPD-1 Specifications
Model: 12038FB-A1N-WPD-1
Brand: NMB (MinebeaMitsumi)
Category: AC Axial Fan
Frame Size: 119 x 119 x 38 mm
Nominal Voltage: 115 VAC
Frequency: 50/60 Hz
Input Power: 17 / 15 W
Rated Current: 0.29 / 0.24 A
Max Airflow: 88 / 105 CFM
Rated Speed: 2500 / 2900 RPM
Bearing Type: Dual Ball Bearing
Frame Material: Aluminum (Die-Cast)
Impeller Material: Plastic (UL 94V-0)
Termination: Lead Wires
Motor Type: Shaded Pole Induction Motor
Protection: Impedance Protected
Operating Temperature: -10 to +70 °C
Storage Temperature: -40 to +70 °C
Mass: 550 g
Included Accessories: Protective Mesh Guard

12038FB-A1N-WPD-1 Applications
Primary applications include integration into industrial server cabinets, CNC machine tool control enclosures, and telecommunications switching equipment. Deployed within power supply cooling systems, medical diagnostic imaging hardware, and automated manufacturing line ventilation modules.
