Description
The AVC 2B06038B12H is a high-density Axial Fan engineered for demanding thermal management environments. Utilizing a brushless DC motor architecture, this unit integrates advanced dual ball bearing systems to minimize friction and extend operational longevity under continuous duty cycles. The aerodynamic impeller design is optimized for high static pressure, overcoming the thermal impedance found in densely packed server enclosures. Its structural rigidity is reinforced by a specialized housing that maintains dimensional stability at peak rotational velocities, ensuring consistent airflow delivery and vibration dampening in mission-critical industrial applications.
Model Number: 2B06038B12H
Brand: AVC
Product Type: Axial Fan
Rated Voltage: 12VDC
Voltage Range: 7.0 – 13.2 VDC
Rated Current: 1.16A
Power: 13.92W
Rated Speed: 12000 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 58.4 CFM (99.2 m³/h)
Max. Static Pressure: 28.5 mmH₂O (279.5 Pa)
Dimensions: 60x60x38mm
Weight: 110g
Life Expectancy: 70,000 Hours at 40C
Speed Control: PWM (Pulse Width Modulation)
Monitoring Output: Tachometer (Frequency Generator)
Termination: 4-Lead Wires
Housing Material: UL94V-0 Reinforced Plastic
Blade Material: UL94V-0 Reinforced Plastic
Operating Temperature: -10C to +70C
Storage Temperature: -40C to +75C
Protection Features: Locked Rotor Protection, Reverse Polarity Protection
Certifications: CE, TUV, UL, RoHS
This high-performance cooling solution is primarily deployed in enterprise-grade server racks and telecommunications infrastructure where the 2B06038B12H provides essential heat dissipation for high-wattage processors. Beyond data centers, the 2B06038B12H is frequently utilized in electric vehicle charging stations and CNC control cabinets to prevent component overheating. Its robust construction also makes it a preferred choice for specialized portable cooling equipment and medical diagnostic hardware requiring reliable, high-pressure airflow.
