6010H05FPF3 T&T 5VDC 0.55A 60x60x10mm Hydraulic Bearing Fan

Description

The T&T 6010H05FPF3 is a high-performance DC axial cooling fan featuring a compact 60 x 60 x 10 mm form factor and a specialized hydraulic bearing system. Operating at a nominal 5 VDC with a current draw of 0.55 A, this unit utilizes a 3-wire interface for power and tachometer signal monitoring. The internal mechanism is constructed with a high-durability hydraulic bearing that reduces friction and noise while maintaining a rotational speed of approximately 4500 RPM. The frame and 7-blade impeller are molded from UL 94V-0 rated thermoplastic PBT, ensuring structural integrity under thermal stress. This fan is designed for low-profile thermal management, providing an airflow of 18.5 CFM and a static pressure rating suitable for dense heat sink dissipation.

6010H05FPF3 Specifications
Model Number: 6010H05FPF3
Brand: T&T
Category: DC Axial Fan
Dimensions: 60 x 60 x 10 mm
Nominal Voltage: 5 VDC
Operating Voltage Range: 4.5 to 5.5 VDC
Rated Current: 0.55 A
Power Consumption: 2.75 W
Rated Speed: 4500 RPM
Maximum Airflow: 18.5 CFM
Static Pressure: 3.2 mmH2O
Noise Level: 32 dBA
Bearing Type: Hydraulic Bearing
Interface: 3-wire (Red: +, Black: -, Yellow: FG/Sensor)
Connector Type: 3-pin small pitch
Material: PBT Plastic (UL 94V-0)
Operating Temperature: -10 to +70 °C
Storage Temperature: -40 to +75 °C
Weight: 25 g
Certifications: CE, RoHS Compliant

6010H05FPF3 Applications
Primary applications include integration into MSI U90, U100, and U120 series netbook thermal modules and low-profile GPU heatsink assemblies. Deployed within compact telecommunications equipment, embedded industrial PC chassis, and portable medical diagnostic devices requiring high-density active cooling in restricted spatial envelopes.
