Description
The Sanyo Denki 9WF1224H1D03 is a robust Axial Fan engineered for demanding industrial environments, belonging to the renowned San Ace 120W series. This unit utilizes a highly efficient DC motor paired with a precision dual ball bearing system to ensure minimal friction and extended operational longevity. Designed with superior aerodynamic geometry, the impeller optimizes airflow while maintaining structural rigidity under thermal stress. The fan features specialized ingress protection, making it suitable for oil-mist and dust-laden atmospheres, significantly reducing thermal impedance in critical electronic enclosures and machinery.
Model Number: 9WF1224H1D03
Brand: Sanyo Denki
Alt. Part Number: A90L-0001-0509 (Fanuc)
Product Type: Axial Fan
Series: San Ace 120W
Rated Voltage: 24VDC
Voltage Range: 20.4 – 27.6 VDC
Rated Current: 0.32 A
Power Input: 7.68 W
Rated Speed: 2600 RPM
Max. Air Flow: 88.3 CFM (150 m³/h / 2.5 m³/min)
Max. Static Pressure: 6.4 mmH₂O (62.7 Pa / 0.25 inH₂O)
Bearing Type: Dual Ball Bearing
Dimensions: 120 x 120 x 38 mm
Weight: 260 g
Ingress Protection: IP55 (Splash/Dust/Oil Proof)
Frame Material: Plastic (UL94V-0)
Impeller Material: Plastic (UL94V-0)
Operating Temperature: -10 to +70°C
Life Expectancy: 40,000 Hours (60°C)
Termination: 3-Wire Lead
Sensor Type: Locked Rotor Sensor
Motor Protection: Current shut off at locked rotor, Reverse Polarity Protection
Dielectric Strength: 50/60 Hz, 500 VAC, 1 minute
The 9WF1224H1D03 is specifically calibrated for high-reliability cooling in industrial automation and CNC machinery. Frequently integrated into Fanuc control systems as part number A90L-0001-0509, this fan ensures stable thermal management for servo amplifiers and power supply units. The 9WF1224H1D03 excels in environments where oil mist or dust is prevalent, such as factory floors, outdoor telecommunication cabinets, and heavy-duty inverters, preventing overheating in critical infrastructure.
