Description
The Sunon A2123-HBT.(7).GN is a robust AC Axial Fan engineered for high-reliability industrial cooling applications. Utilizing a precision Ball Bearing system, this unit ensures longevity and stable operation under continuous duty cycles. The 120mm frame houses a dynamically balanced 7-blade impeller designed to optimize aerodynamic efficiency, delivering substantial airflow while maintaining structural rigidity. Operating at 220-240VAC, the fan features an aluminum alloy housing that aids in thermal dissipation and vibration dampening. Its capacitor-run induction motor provides consistent torque and speed stability, making it an ideal solution for environments requiring dependable thermal management with minimal maintenance requirements.
Model Number: A2123-HBT.(7).GN
Brand: Sunon
Product Type: AC Axial Fan
Rated Voltage: 220-240VAC
Frequency: 50/60 Hz
Rated Current: 0.14/0.12 A
Power Consumption: 23/20 W
Rated Speed: 2500/2750 RPM
Bearing Type: Ball Bearing
Max. Air Flow: 117.0 CFM (198.7 m³/h / 3.31 m³/min)
Max. Static Pressure: 11.17 mmH₂O (109.5 Pa / 0.44 inH₂O)
Dimensions: 120x120x38mm
Weight: 525g
Housing Material: Aluminum Alloy
Impeller Material: Thermoplastic PBT (UL94V-0)
Termination: Terminals
Operating Temperature: -10 to +70°C
Motor Type: Capacitor-Run Induction Motor
Noise Level: 45/50 dB(A)
Safety: Impedance Protected
Phase: Single Phase
Direction of Rotation: Counter-clockwise viewed from front of blade face
Designed for versatile industrial integration, the A2123-HBT.(7).GN excels in ventilating control cabinets, server racks, and power supply units where consistent AC power is available. The robust construction allows the A2123-HBT.(7).GN to operate effectively in manufacturing machinery and telecommunications enclosures, ensuring critical components remain within safe thermal operating limits.
