Description
The Nidec D06F-24SH01B is a precision-engineered DC Axial Fan designed for critical thermal management in industrial environments. Part of the renowned GAMMA27 series, this unit leverages advanced motor technology to deliver an optimized P-Q curve, ensuring high airflow delivery against significant static pressure resistance. The chassis is constructed for maximum structural rigidity, minimizing vibration-induced noise while maintaining consistent performance under thermal stress. Its aerodynamic impeller design reduces turbulence, effectively lowering thermal impedance in high-density electronic enclosures, making it a robust solution for continuous duty cycles.
Model Number: D06F-24SH01B
Brand: Nidec
Series: GAMMA27
Product Type: DC Axial Fan
Rated Voltage: 24VDC
Operating Voltage Range: 14.0 – 27.6 VDC
Rated Current: 0.16 A
Input Power: 3.84 W
Rated Speed: 4500 RPM
Max. Air Flow: 23.5 CFM (39.9 m³/h)
Max. Static Pressure: 5.8 mmH₂O (56.9 Pa)
Noise Level: 34.0 dB-A
Dimensions: 60 x 60 x 25 mm
Bearing Type: Maintenance-Free Ball Bearing
Termination: 3-Wire (Lead Wire)
Wire Function: Red (+), Black (-), White/Yellow (Signal/Tachometer)
Housing Material: PBT (UL94V-0)
Impeller Material: PBT (UL94V-0)
Operating Temperature: -10°C to +70°C
Life Expectancy: 70,000 Hours at 40°C
Weight: 65 g
Ingress Protection: IP20
The D06F-24SH01B is engineered for demanding applications requiring reliable forced-air cooling, such as industrial automation control panels, telecommunications equipment, and compact server power supplies. Its robust design makes the D06F-24SH01B ideal for medical instrumentation and CNC machinery where consistent thermal dissipation is critical for component longevity and system stability.
