Description
The SUNON EF50060S1-C470-G9A is a DC Blower Fan engineered for high-density thermal management in compact mobile computing environments. Utilizing advanced brushless motor technology, this unit is optimized for low thermal impedance and high structural rigidity within a slim-profile form factor. The aerodynamic impeller design is specifically calibrated to maximize static pressure while maintaining minimal acoustic signatures. Its sleeve bearing architecture ensures reliable operation under varying mounting orientations, providing a stable cooling solution for integrated circuits and heat sink assemblies that require precise airflow redirection.
Model Number: EF50060S1-C470-G9A
Brand: SUNON
Product Type: DC Blower Fan
Rated Voltage: 5VDC
Voltage Range: 4.5 – 5.5 VDC
Rated Current: 0.40A
Power: 2.0W
Rated Speed: 4500 RPM
Bearing Type: Sleeve Bearing
Max. Air Flow: 3.5 CFM
Max. Static Pressure: 0.45 inH2O
Dimensions: 50mm x 50mm x 6mm
Weight: 25g
Life Expectancy: 30,000 Hours at 40C
Termination: 3-Wire Lead (Tachometer/Signal)
Connector: Dell Proprietary 0X6K70
Housing Material: Thermoplastic PBT (UL94V-0)
Blade Material: Thermoplastic PBT (UL94V-0)
Operating Temperature: -10C to +70C
Storage Temperature: -40C to +70C
Protection Features: Locked Rotor Protection, Auto Restart
Certifications: CE, TUV, UL, RoHS
This cooling component is primarily utilized as the primary thermal dissipation unit for Dell Latitude 3480 and 3580 series laptops. The EF50060S1-C470-G9A is essential for maintaining optimal CPU temperatures during high-load processing tasks, preventing thermal throttling in P79G chassis models. Due to its specialized slim blower geometry, the EF50060S1-C470-G9A is also suitable for ultra-thin industrial controllers and portable medical diagnostic equipment where vertical space is severely restricted.
