F2.179.2111/05 Heidelberg 24VDC 120x120x32mm Blower

Description

The Heidelberg F2.179.2111/05 is a Blower engineered for high-precision thermal management within industrial printing environments. Utilizing advanced DC brushless motor technology, this unit minimizes thermal impedance while maximizing structural rigidity through its reinforced housing. The dual ball bearing architecture ensures extended service life and stability under continuous duty cycles. Its optimized centrifugal impeller design is specifically calibrated to provide concentrated airflow, essential for maintaining the operational integrity of sensitive electronic components and mechanical assemblies in high-speed printing machinery.

Model Number: F2.179.2111/05
Brand: Heidelberg
Product Type: Blower
Rated Voltage: 24VDC
Voltage Range: 18.0 – 27.6 VDC
Rated Current: 1.25 A
Power: 30.0 W
Rated Speed: 3500 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 45.5 CFM (77.3 m³/h / 1.29 m³/min)
Max. Static Pressure: 42.8 mmH₂O (420 Pa / 1.68 inH₂O)
Dimensions: 120x120x32mm
Weight: 250g
Life Expectancy: 70,000 Hours at 40C
Noise Level: 55.0 dBA
Housing Material: Thermoplastic PBT (UL94V-0)
Blade Material: Thermoplastic PBT (UL94V-0)
Termination: 2-Lead Wires
Operating Temperature: -20C to +70C
Storage Temperature: -40C to +80C
Ingress Protection: IP54
Insulation Class: Class A
Protection Features: Locked Rotor Protection, Reverse Polarity Protection
Certifications: CE, RoHS, UL

This blower is primarily integrated into Heidelberg offset printing presses to facilitate critical component cooling and air cushion generation. The F2.179.2111/05 is essential for preventing overheating in the main drive cabinets and electronic control units. In demanding industrial environments, the F2.179.2111/05 provides the reliable pneumatic pressure required for paper handling and ink drying processes.

Updated: 2026-03-01 02:51

Additional information

Shipping Weight	1 kg
