F4010GB-24UCV ICFAN 24V 0.17A 40x40x10mm DC Axial Fan

Description

ICFAN F4010GB-24UCV is a 40 x 40 x 10 mm compact axial cooling fan operating at a nominal 24 VDC with a 0.17 A current draw and a 4.08 W power rating. Constructed with a highly durable metal impeller, this unit is engineered to withstand elevated thermal conditions while delivering substantial airflow capacity. The hardware features a standard two-wire interface for direct DC power integration and utilizes a robust dual ball bearing mechanism to ensure extended operational longevity under continuous mechanical stress.

F4010GB-24UCV Specifications
Model Number: F4010GB-24UCV
Brand: ICFAN
Product Category: DC Axial Cooling Fan
Nominal Voltage: 24 VDC
Rated Current: 0.17 A
Power Consumption: 4.08 W
Dimensions: 40 x 40 x 10 mm
Impeller Material: Metal
Bearing Type: Dual Ball Bearing
Connection Interface: Two-Wire (Bare Leads)
Thermal Resistance: High Temperature Rated
Airflow Characteristic: High Volume Output
Motor Type: Brushless DC

F4010GB-24UCV Applications
Primary applications include integration into industrial frequency inverters, compact power supply units, and high-density telecommunications equipment. Deployed within CNC control cabinets, extrusion heads, and automated optical inspection systems requiring localized thermal management. Utilized extensively in server racks and medical diagnostic machinery where space-constrained, high-temperature heat dissipation is critical.
