Description
The KAKU KA2880HA2 is a high-capacity AC Axial Fan designed to deliver superior thermal management in demanding industrial environments. Engineered with a robust AC induction motor and a precision ball bearing system, this unit ensures exceptional operational stability and extended service life under continuous duty cycles. The fan features a durable die-cast aluminum frame that provides high structural rigidity and aids in heat dissipation, while the aerodynamically optimized impeller maximizes airflow efficiency. This configuration significantly reduces thermal impedance, making it a reliable choice for critical cooling applications requiring high static pressure and volume.
Model Number: KA2880HA2
Brand: KAKU
Product Type: AC Axial Fan
Rated Voltage: 220-240 VAC
Frequency: 50/60 Hz
Rated Current: 0.57 / 0.64 A
Input Power: 115 / 150 W
Rated Speed: 2550 / 2700 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 1090 CFM (1850 m³/h / 30.8 m³/min)
Max. Static Pressure: 22.5 mmH₂O (220 Pa / 0.88 inH₂O)
Dimensions: 280 x 280 x 80 mm
Weight: 2.8 kg
Frame Material: Aluminum Alloy Die-Cast
Impeller Material: Reinforced Plastic / Metal
Noise Level: 70 dBA
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +80°C
Life Expectancy: 50,000 Hours at 25°C
Termination: Terminal Block / Lead Wire
Ingress Protection: IP54
Insulation Class: Class B
Mounting Orientation: Any
The KA2880HA2 is specifically engineered for heavy-duty applications such as large electrical control cabinets, power distribution units, and industrial automation machinery. Its high airflow capacity makes the KA2880HA2 ideal for ventilating server rooms, CNC equipment, and telecommunications base stations where maintaining optimal operating temperatures is essential for equipment reliability and longevity.
