MGT8012UB-R25G Protechnic 12VDC 0.82A 80x80x25mm IP68 Fan

Description

Protechnic MGT8012UB-R25G is an 80 x 80 x 25 mm axial cooling fan operating at 12 VDC with a 0.82 A current draw. It features a dual ball bearing system and a PBT thermoplastic housing and impeller rated for UL 94V-0 flammability. The unit provides an IP68 ingress protection rating, ensuring full submersion capability and dust resistance. Internal electronics are encapsulated for environmental sealing, supporting a 3-wire interface for tachometer output.

MGT8012UB-R25G Specifications
Model: MGT8012UB-R25G
Brand: Protechnic Electric
Dimensions: 80 x 80 x 25 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 7.0 to 13.8 VDC
Rated Current: 0.82 A
Rated Power: 9.84 W
Rated Speed: 4800 RPM
Maximum Airflow: 68.88 CFM
Maximum Static Pressure: 9.17 mmH2O
Bearing Type: Dual Ball Bearing
Ingress Protection: IP68
Noise Level: 45.2 dBA
Material: PBT Plastic (UL 94V-0)
Termination: 3-wire Lead
Operating Temperature: -10 to +70 °C
Storage Temperature: -40 to +75 °C
Life Expectancy: 70,000 hours at 40 °C
Safety Approvals: UL, TUV, CE
Weight: 95 g

MGT8012UB-R25G Applications
Primary applications include integration into outdoor telecommunications enclosures, industrial server chassis, and high-density power supply cooling systems. Deployed within CNC control cabinets and marine electronic navigation arrays requiring IP68-rated thermal management.
