MGT9212ZB-W25K Protechnic 12VDC 0.48A 92x92x25mm Axial Fan

Description

Protechnic MGT9212ZB-W25K 92 x 92 x 25 mm, 12 VDC, 0.48 A, and 79.8 CFM axial cooling fan features a dual ball bearing system and a PBT thermoplastic housing rated UL 94V-0. It utilizes a 4-wire PWM interface for speed control and provides IP 55 ingress protection against dust and moisture. The internal motor architecture supports high-velocity airflow at a rotational speed of 4800 RPM.

MGT9212ZB-W25K Specifications
Model: MGT9212ZB-W25K
Brand: Protechnic Electric
Category: DC Axial Fan
Dimensions: 92 x 92 x 25 mm
Voltage: 12 VDC
Current: 0.48 A
Power: 5.76 W
Bearing Type: Dual Ball Bearing
Speed: 4800 RPM
Airflow: 79.8 CFM
Noise Level: 49.5 dBA
Interface: 4-wire PWM
Ingress Protection: IP 55
Material: PBT Plastic (UL 94V-0)
Weight: 131 g

MGT9212ZB-W25K Applications
Primary applications include integration into industrial server chassis, telecommunications rack cooling systems, and CNC control cabinet ventilation. Deployed within high-density power supply units and automated industrial workstations requiring moisture-resistant thermal management.
