9GV0412P3J16 Sanyo Denki 12VDC 40x28mm Cooling Fan

Description

Sanyo Denki 9GV0412P3J16 is a 40 x 40 x 28 mm high-performance DC axial fan operating at a nominal 12 VDC with a rated current of 0.60 A. This unit features a dual ball bearing system and a plastic frame and impeller meeting UL 94V-0 flammability standards. It delivers a maximum airflow of 0.64 m³/min (22.6 CFM) and a maximum static pressure of 430 Pa. The fan includes a pulse width modulation (PWM) speed control interface and a tachometer output for precise thermal management.

9GV0412P3J16 Specifications
Model: 9GV0412P3J16
Brand: Sanyo Denki
Series: San Ace 40 GV
Frame Size: 40 x 40 x 28 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 10.2 to 13.8 VDC
Rated Current: 0.60 A
Rated Input: 7.2 W
Rated Speed: 17,000 RPM
Max Airflow: 0.64 m³/min
Max Airflow: 22.6 CFM
Max Static Pressure: 430 Pa
Max Static Pressure: 1.73 inchH2O
SPL (Sound Pressure Level): 54 dB (A)
Operating Temperature: -20 to +70 °C
Storage Temperature: -30 to +70 °C
Expected Life: 40,000 hours at 60 °C
Bearing Type: Dual Ball Bearing
PWM Control: Yes
Sensor: Pulse Sensor (Tachometer)
Material Frame: Plastic (UL 94V-0)
Material Impeller: Plastic (UL 94V-0)
Mass: 53 g

9GV0412P3J16 Applications
Primary applications include integration into 1U and 2U rackmount server chassis, high-density telecommunications switching equipment, and enterprise-grade network routers. Deployed within power supply units and compact industrial computing modules requiring high static pressure for dense component cooling.
