DW-01 Hitachi Elevator Eddy Current Load Sensor

Description

The Hitachi DW-01 is a high-precision eddy current sensor engineered for non-contact load detection and car bottom weighing in elevator systems. Utilizing electromagnetic induction to measure distance variations between the sensor and the elevator car frame, it provides real-time feedback for overload protection and floor leveling accuracy. This industrial-grade component features a robust housing designed to withstand the high-vibration environment of elevator shafts while maintaining a stable output signal for the lift controller.

DW-01 Specifications
Model Number: DW-01
Brand: Hitachi
Product Category: Elevator Sensors / Eddy Current Sensors
Sensing Technology: Non-contact Eddy Current Induction
Primary Function: Car Bottom Weighing and Load Detection
Compatibility: Hitachi Elevator Systems (LGE, MCA, HGP series)
Operating Voltage: Standard Elevator Control Logic Levels
Output Type: Analog/Digital Signal Feedback
Installation Location: Elevator Car Bottom / Hood Frame
Material: High-durability Industrial Polymer/Metal Housing
Protection Rating: IP-rated for Dust and Moisture Resistance
Operating Temperature: -10 to +60°C
Certifications: OEM Original Equipment Manufacturer Standard
Weight: Approx. 0.35kg
Dimensions: Compact form factor for under-car mounting

DW-01 Applications
Mandatory load-sensing and weighing management for Hitachi passenger and freight elevators, specifically integrated into car bottom frames for overload prevention and pre-torque motor control. Technical implementation includes real-time floor leveling compensation and safety circuit feedback in high-rise traction lift systems.
