Description
The Royal Fan TAR475CH-10-B66 is a robust AC Axial Fan engineered for high-reliability industrial thermal management. Utilizing an advanced AC induction motor architecture, this unit delivers consistent airflow performance while maintaining optimal thermal impedance under continuous operation. The construction features a die-cast aluminum frame, providing exceptional structural rigidity and resistance to environmental stress. Designed with precision ball bearings, the TAR475CH-10-B66 ensures longevity and stability, making it an ideal solution for critical cooling applications requiring durable aerodynamic efficiency and effective heat dissipation in 200VAC systems.
Model Number: TAR475CH-10-B66
Brand: Royal Fan (Ikura Seiki)
Product Type: AC Axial Fan
Rated Voltage: 200 VAC
Frequency: 50 / 60 Hz
Voltage Range: 180 – 220 VAC
Rated Current: 0.11 / 0.09 A
Input Power: 14.0 / 12.0 W
Rated Speed: 2700 / 3100 RPM
Bearing Type: Dual Ball Bearing
Max. Air Flow: 95.0 CFM (161.4 m³/h / 2.69 m³/min)
Max. Static Pressure: 7.5 mmH₂O (73.5 Pa / 0.29 inH₂O)
Dimensions: 120 x 120 x 38 mm
Weight: 550 g
Frame Material: Aluminum Die-Cast
Impeller Material: Reinforced Plastic UL94V-0
Motor Protection: Impedance Protected
Insulation Resistance: 100MΩ at 500VDC
Dielectric Strength: 1500VAC for 1 minute
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Life Expectancy: 50,000 Hours at 25°C
Termination: Lead Wires / Terminal Block
Mounting Orientation: Any
Noise Level: 42 / 46 dB(A)
Certifications: UL, CSA, TUV
This cooling solution is extensively utilized in industrial automation environments, specifically within control panels and server cabinets where reliable thermal regulation is paramount. The TAR475CH-10-B66 is frequently integrated into CNC machinery electronics, power supply units, and telecommunications infrastructure to prevent thermal throttling. By maintaining optimal operating temperatures, the TAR475CH-10-B66 safeguards sensitive components in factory automation systems and heavy-duty electrical enclosures.
