Description
The AVC DBPA22A0B8H-Y001 is a high-capacity Centrifugal Fan engineered for demanding industrial thermal management and high-impedance systems. Featuring a robust aluminum die-cast frame and a precision-balanced motorized impeller, this unit ensures exceptional structural rigidity and vibration dampening under high-speed operation. The 48VDC motor utilizes advanced commutation electronics to deliver substantial airflow while maintaining optimized thermal impedance. Designed with specific ingress protection features, it offers reliability in harsh environments, making it suitable for critical cooling applications requiring sustained static pressure and durability against moisture and contaminants.
Model Number: DBPA22A0B8H-Y001
Brand: AVC (Asia Vital Components)
Product Type: Centrifugal Fan / Blower
Rated Voltage: 48 VDC
Voltage Range: 36.0 – 57.0 VDC
Rated Current: 4.08 A
Power Input: 195.8 W
Rated Speed: 3800 RPM
Max. Air Flow: 720.0 CFM (1223 m³/h / 20.3 m³/min)
Max. Static Pressure: 3.85 inH₂O (958 Pa / 97.7 mmH₂O)
Dimensions: 225 x 225 x 80 mm
Bearing Type: Dual Ball Bearing
Frame Material: Aluminum Die-Cast
Impeller Material: Reinforced Plastic UL94V-0
Ingress Protection: Waterproof (IP Rated)
Noise Level: 68.5 dB(A)
Termination: Lead Wires
Operating Temperature: -10°C to +70°C
Storage Temperature: -40°C to +70°C
Life Expectancy: 70,000 Hours at 40°C
Weight: 1.85 kg
Mounting Orientation: Any
Safety Certifications: CE, UL, TUV
The DBPA22A0B8H-Y001 is frequently deployed in telecommunications infrastructure and large-scale server cabinets where high static pressure is required to overcome significant system resistance. Industrial automation systems utilize the DBPA22A0B8H-Y001 for active cooling of variable frequency drives, power inverters, and CNC machinery. Additionally, this model serves effectively in outdoor enclosures and renewable energy inverters due to its robust aluminum construction and waterproof capabilities, ensuring consistent performance in challenging environmental conditions.
