MGA6024HB-O25-IP68 Protechnic 24VDC 60x60x25mm 0.14A Axial Fan

Description

Protechnic MGA6024HB-O25-IP68 is a 60 x 60 x 25 mm axial cooling fan operating at a nominal 24 VDC with a 0.14 A current draw. The unit features a dual ball bearing system and a PBT thermoplastic housing rated to UL 94V-0 standards. It delivers an airflow of 23.5 CFM and a static pressure of 0.28 in-H2O at a rotational speed of 4500 RPM. The internal motor is fully encapsulated to achieve an IP 68 ingress protection rating against moisture and particulates.

MGA6024HB-O25-IP68 Specifications
Model: MGA6024HB-O25-IP68
Brand: Protechnic Electric
Dimensions: 60 x 60 x 25 mm
Rated Voltage: 24 VDC
Operating Voltage Range: 14.0 to 27.6 VDC
Rated Current: 0.14 A
Input Power: 3.36 W
Rated Speed: 4500 RPM
Maximum Airflow: 23.5 CFM
Static Pressure: 0.28 in-H2O
Noise Level: 36.5 dBA
Bearing Type: Dual Ball Bearing
Ingress Protection: IP 68
Frame Material: Thermoplastic PBT (UL 94V-0)
Impeller Material: Thermoplastic PBT (UL 94V-0)
Termination: 2-Wire Lead
Operating Temperature: -10 to +70 °C
Storage Temperature: -40 to +70 °C
Weight: 65 g
Life Expectancy: 70,000 Hours at 40 °C

MGA6024HB-O25-IP68 Applications
Primary applications include integration into outdoor telecommunications enclosures, industrial server chassis, and ruggedized power supply units requiring moisture resistance. Deployed within CNC control cabinets and automated manufacturing equipment for localized thermal management in high-humidity environments.
